| Model | WIFI-MR50-36S/H |
| Camera | |
| APP | CAMHI / CAMHIPRO/ Xmeye |
| Image sensor | 1/2.8″ CMOS HI3516EV300+SONY IMX335 |
| focus | 36X Optical zoom (4.7mm – 94mm) |
| Max resolution | 5MP |
| Minimum Illumination |
Color: 0.01Lux, B/W: 0.001Lux,0 Lux with IR (Starlight) |
| Storage | support max 128G TF card |
| 3D DNR | Support |
| WDR | 1/7.5s—1/2000s, AUTO |
| Electronic shutter | Yes |
| Day-night mode | Auto ICR color to B/W |
| Mainstream | 20fps:（2952*1920 , 25fps：(1920×1080)、 (1280×960), (1280×720) |
| Sub-stream | 25fps：(704×576), (640×480), (648×360) |
| Video compression | H.265, H.265+, H.264 |
| Network protocol | HTTP, FTP, SMTP, UPnP, SNMP, DDNS, NTP, RTSP, RTP, TCP, DHCP, PPPoE |
| interface | ONVIF, GB/T.28181 |
| PTZ | |
| IR Distance | 120m |
| Horizontal scan | 0°～355°continuously |
| Vertical range | -15°～90°（auto flip） |
| Horizontal speed | 0.05°～60°/s |
| Vertical speed | 0.05°～60°/s |
| Max speed | 60°/S |
| preset | 256 |
| Patrol scan | 4pcs（10 preset for each） |
| R/L Scan | 1 |
| Horizontal scan | 1 |
| POWER UP ACT | Watch position/L/R Scan/Horizontal 355°scan/Patrol scan |
| PARK ACT | Watch position/L/R Scan/Horizontal 355°scan/Patrol scan |
| Watch position | 1 |
| General | |
| Power | DC 12V/4A |
| Consumption | ＜18W |
| Working environment |
temp-20～60℃； humidity＜90% |
| Protection | IP66 |
| GW | 2.0KG |
| SIZE (MM) | 185*185*290 mm |
Wifi PTZ Camera
● 8 pcs High-quality array smart LEDs to support starlight effect, 120M IR distance.
● Built-in 5db WIFI module, the partition can transmit 30 meters.
● Storage video by SD card, max support 128G TF card.
● High-performance encoding scheme with CMOS image sensor for the clear and dynamic image.
● Support 5A Features: Auto white balance, Autofocus, Auto exposure, Auto noise reduction, Auto contrast enhancement.
● Fully compatible with the ONVIF protocol and GB28181 protocol.
● High precision motor, precise control, smooth motion, stable rotation.
● Adopt a high-performance platform, stable and reliable. Support dual-stream, H.265/ H.265+ video compression. Support multiple levels of video quality configuration.
● Infrared light and magnification range matching algorithm based on IR distance, brightness, and angle for best image quality.
● Ingress Protection: IP66.
